SEQURE 5S-12S 200A Brushless ESC with Forward/Reverse/Brake - BLHeli_32 Firmware (No BEC) for FPV Drones, Quadcopters & Multi-axis Drones - Perfect for Racing, Freestyle & Aerial Photography

Specification Model SQESC 12200 Processor STM32G071 Input voltage DC 18V-50.4V(5-12S Lipo) Continuous Current 200A Peak Current 250A Support firmware AM32/BLHeli_32 Signal Protocols Dshot (All), PWM, Oneshot, Multishot, etc. Functions Forward, Reverse, Brake Program parameter adjustments Yes Steering Setting of the Motor Yes Accelerator calibration Yes Boost Timing Setting Yes Current Detection Yes Telemetry signal Yes RGB LED Light Yes Features Adopting 32-bit high-performance processor STM32G071, with a working frequency of up to 64MHz and maximum support 128KHz motor PWM frequency. Adopts high-power MOSFET, and combined with CNC metal radiator, this esc dissipates heat effectively under high current load and works stably & continuously. The ESC automatically detects the throttle signal when it is powered on, supports all Dshot signals, and also supports signal protocols such as PWM, Oneshot and Multishot. Visual programming parameter adjustment tool supports motor timing, throttle calibration, current detection, motor steering, telemetry signal and other settings. Onboard RGB LED color light settings, multiple LED colors can be customized. Widely used in model airplane plant protection machines, multi-rotor drones, RC model ships and cars. Wiring Diagram Product Photograph Comparison SEQURE 200A 5-12S ESC Add to Cart SEQURE 70A 2-6S ESC Buying Options SEQURE 100A 5-12S ESC Add to Cart SEQURE 120A 2-8S ESC Add to Cart SEQURE 70A 4IN1 ESC Add to Cart Customer Reviews 3.0 out of 5 stars 1 5.0 out of 5 stars 6 — — 3.4 out of 5 stars 3 Price $109.99$109.99 — $59.99$59.99 $54.99$54.99 $79.99$79.99 Model SQESC 12200 SQESC 2670 SQESC 12100 SQESC 12200 E70 G1 Firmware AM32 AM32 AM32 AM32 AM32 Processor STM32G071 STM32G071 STM32G071 STM32G071 STM32G071 Input voltage DC 18V-50.4V(5-12S Lipo) DC 7V-25.2V(2-6S Lipo) DC 18V-50.4V(5-12S Lipo) DC 7V-33.6V(2-8S Lipo) 2-8S Lipo Continuous current 200A 70A 100A 120A 70A Maximum current 250A 110A 180A 150A 150A BEC ✘ ✔ ✘ ✘ ✘
